It is manipulated with the touch button of the adjacent sensor mode. Simply place your club on the button until the inclination reaches the desired slope. To change direction, initialize it with the square-shaped button in the middle, and press the direction button.
[Swing Dr. I]
How much electricity does it consume?
It can be operated with basic power without additional wiring work. During operation, it consumes around 4A. During idle time, it is locked mechanically.
[Swing Dr. I]
Can the lawn mat be replaced?
The lawn mat is a consumable product that can be replaced. As the foothold mat and iron mat can be separated, replacing only the iron mat is possible as well.
[Swing Dr. I]
How much weight it can withstand?
In idle time, it can withstand up to 500Kg. During operation it depends on the situation, but usually it is safe up to 140Kg.
[Swing Dr. I]
What is the product's mechanical lifespan?
The product lifespan may differ depending on the user environment. Unlike the hydraulic type, its mechanical structure does not require any maintenance and will last for a long time.
[Swing Dr. II]
What are the A/S terms?
A/S is provided free of charge (excluding the replacement of consumables) for one year. Thereafter, travel expenses and parts replacement will be charged separately under the A/S terms and conditions. Please contact 82-31-904-7302 to request rapid A/S processing.
SWING Dr. II
[Swing Dr. II]
With what kinds of screen golf system can it be used?
In fact, it can be adapted to all kinds of screen golf systems. Please contact the manufacturer of the system you are using for consultation on setting.
[Swing Dr. II]
To install it at a screen golf range, I need to know how much space is required for installation.
The product dimensions are 1,110×1,610×130(mm), so 1,140×1,640×140(mm) would be fine as the installation dimension of booth for hitting board.
[Swing Dr. II]
How high can it be raised?
It can be raised up to 300mm or more, but it is locked for safety reasons.
[Swing Dr. II]
How to use it?
Swing Dr. II can replicate the inclination of a golf course in real time via the screen golf program, so no separate manipulation by the user is required during play. For your safety, please step down from the foothold while it is moving to make the required inclination.
[Swing Dr. II]
How much weight can it support?
In idle time, it can withstand up to 700Kg. During operation it depends on the situation, but usually it is safe up to 200Kg.
[Swing Dr. II]
Can a user change inclination?
It is possible if a driving program for the Swing Dr. is installed. You can download the program from the Quick Menu on the right-hand side of our homepage.
Auto Tee-up System
[Auto Tee-up System]
What is the main advantage of the slim type auto tee-up machine as regards construction?
This super-slim product with a height of just 11cm does not require an open slot for installation on a super deck or curved deck in outdoor driving ranges, and can be installed with direct welding, which significantly reduces the construction cost and time.
[Auto Tee-up System]
What is the product's lifespan?
MIRIP's auto tee-up system features an expensive AC motor whose system and structure differ considerably from that of a cheap DC motor. In terms of durability and lifespan, it can maintain its functions for a long period. Our technician will advise you on how best to maintain it at the time of installation.
[Auto Tee-up System]
What is the height of the machine?
Unlike the existing auto tee, the height of MIRIP's slim-type auto tee-up is 11cm, which leaves sufficient space between ceiling and floor, provides a broad range of vision and comfort to the player, and reduces the cost of outdoor driving range construction.
[Auto Tee-up System]
Can it be interlocked with screen golf?
The slim type auto tee-up function can be used with any screen golf system. Please contact the relevant screen golf system manufacturer for further details.
[Auto Tee-up System]
How high can the tee's height can be raised?
The height from the machine is 100mm. If you use a lawn mat (30mm), the actual height will be 70mm. The range of adjustment of the tee's height is 0mm~70mm, and it is adjustable by 5mm.
[Auto Tee-up System]
What is the life of the rubber tee?
A rubber tee is a consumable product whose lifespan may differ depending on the amount of use. This company's rubber tee is made of elastic rubber to ensure a long lifespan.
[Auto Tee-up System]
Is it hard to replace a rubber tee?
It is very simple. Simply refer to the manual to replace it, and our technician will let you know how to replace and maintain it when he installs it.
[Auto Tee-up System]
What are auto mode and step mode?
The auto mode, which is used on a normal driving range, places a ball on the tee automatically whenever the tee is empty. The step mode supplies a ball when the user presses the switch, or by program command from the screen golf system. In this mode the tee will go down if there is no ball on it.
[Auto Tee-up System]
How long does it take to install the product?
Product installation takes about one day if the booth has already been built.
